KW Weifang Genset Technical Parameters |
|||||
|
Generator Model |
BD-20GF/-150GF |
Output Power |
20KW-150KW |
Steady state Frequency Regulation |
≤±1% |
|
Rated Voltage |
400/230V |
Stable Voltage Regulation |
≤±1% |
Transient Frquency Regulation |
≤±10% |
|
Rated Current |
36A-1800A |
Transient Voltage regulation |
≤±15% |
Frequency Stabilization Time |
≤3S |
|
Rated Frequency |
50HZ |
Voltage Setting Time |
≤1S |
Frequency Fluctuation |
≤±0.5% |
|
Weight |
630KG-1530KG |
Voltage Fluctuation |
≤±0.5% |
Size |
customized |
|
Text power |
25kva-187.5kva |
Rated Speed |
1500RPM |
Noise |
95dB(A) |
|
Diesel Parameters |
|||||
|
Generator Model |
|
Rated Power |
20KW-150KW |
Overload Power |
22KW-165KW |
|
Cylinders No |
Four/Six /Cylinders |
Speed |
1500RPM |
Starting Model |
DC24V Electricity |
|
Type |
Four Stroke |
Intake Type |
Normally Aspirated /turbo charge |
Fuel Consumption(g/kw.h) |
≤236-238 |
|
Coling Method |
Closed Cooling Water |
Lubrication Method |
Combined pressure and splash |
Cylinder Diameter/Distance of travel |
100/115mm 113/115mm |
|
Fuel Feeding Method |
direct injection |
Speed Regulation |
Mechanical Speed Governors |
Engine displacement |
3.6L |
|
Fuel Type/Fuel Class |
China 0#(Light diesel oil) |
Compression Rate |
19:01 |
Manufacturer |
Weifang |
|
Generator Parameters |
|||||
|
Generator Model |
|
Rated Voltage |
400V/230V |
|
|
|
Type |
All the copper Brushless |
Electrical Made |
Three-phase four-wire,neutral ground |
|
|
|
Model |
|
Steady state Frequency Regulation |
≤±1% |
|
|
|
Frequency |
50Hz |
Short circuit protection |
Air Switch |
|
|
|
Insulation Class |
H |
Short-time Current |
150% 2min |
|
|
|
Protection Level |
IP23 |
Overload Capacity |
Overload 10% one hour |
|
|
|
Power Factor |
0.8(Hysteresis) |
Power |
20KW-150KW |
|
|
|
Rated Rurrent |
36A-270A |
Adjust Method |
AVR(automatic voltage regulator) |
|
|
|
Exciter Type |
Brushless Excitation |
Cooling Method |
Self-Cooled |
|
|
